Overview:
The Turbosan NORM Series end suction pumps are designed for pumping clean, non-abrasive, low-viscosity liquids without solid particles. These pumps are ideal for applications requiring continuous operation and high reliability.
Key Features:
Design: End suction, single-stage, volute casing.
Materials: Cast iron volute and impeller; C-1040 carbon steel shaft; stainless steel shaft sleeve.
|
Rated Capacity (gpm) |
Rated Capacity (m³/h) | Size (in.) | Model Designation | Rated Net Pressure Range (psi) | Rated Net Pressure Range (mwc) |
Max Working Pressure (psi) |
|
300 |
68 | 4×3 | NORM EFF 80/200A | 94–149 | 66 – 104.7 | 151 |
| 400 | 91 | 4×3 | NORM EFF 80/200A | 62–103 | 43.5 – 72.4 |
151 |
|
450 |
102 | 4×3 | NORM EFF 80/200A | 60–102 | 42 – 71.7 | 151 |
| 500 | 114 | 4×3 | NORM EFF 80/200A | 56–101 | 39.3 – 71 |
151 |
|
750 |
170 | 6×5 | NORM EFF 125/200 | 76–129 | 53.3 – 90.5 | 132 |
| 1000 | 227 | 6×5 | NORM EFF 125/200 | 74–128 | 51.6 – 90 |
132 |
|
1250 |
284 | 6×5 | NORM EFF 125/200 | 71–126 | 49.8 – 88.6 | 132 |
| 1500 | 341 | 6×5 | NORM EFF 125/200 | 65–121 | 45.6 – 85 |
132 |
|
750 |
170 | 6×5 | NORM SN 125/250 | 119–187 | 83.6 – 131.4 |
192 |
|
1000 |
227 | 6×5 | NORM SN 125/250 | 118–187 | 83 – 131.4 |
192 |
|
1250 |
284 | 6×5 | NORM SN 125/250 | 115–185 | 80.8 – 130 |
192 |
|
1500 |
341 | 6×5 | NORM SN 125/250 | 111–183 | 78 – 128.6 |
192 |
|
500 |
114 | 5×4 | NORM SN 100/250 | 113–206 | 79.4 – 144.8 |
208 |
|
750 |
170 | 5×4 | NORM SN 100/250 | 111–205 | 78 – 144 |
208 |
|
1000 |
227 | 5×4 | NORM SN 100/250 | 103–203 | 72.4 – 142.7 |
208 |
| 1250 | 284 | 5×4 | NORM SN 100/250 | 98–202 | 69 – 142 |
208 |
